5-10 ton Heli forklifts are large-tonnage vehicles and are the vehicles that ensure stability, efficiency and the most fuel economy among Chinese forklift brands. Why is this Heli forklifts line trusted by many large customers in fields such as stone exploitation, concrete, wood, steel, aluminum, river port systems and sea ports?. Let’s find out specifically in the article below.
Features of the 5-10 ton Heli forklift
Damping
With suspension damping structure on overhead guard(cab) and optimized design for the transmission, the whole trucks’s vibration reduced a lot and relieve driver’s fatigue greatly.
Noise reduction
Equipped with fully sealed cab and optimize designed parts around the engine, noise nearby ear and the truck sound level are reduced greatly.
Heat dissipation
With the optimized cooling system and great cooling performance, highly improved the reliability and durability of the transmission and engine, etc, many key parts.
Energy efficiency
With optimized hydraulic system, the truck is more energy-efficient and lower fuel consumption.
Comfort
Man-machine engineering design improves operation comfort; wide view lifting system improves vision.
Intelligent gear shifting
With electronic-hydraulic reversing systerm as standard configuration, make operation more liaght and easy; The updated new intelligent gear shifting system could avoid starting with second gear, improves the transmission box’s realiability.
Maintainability
Wider internal space, more reasonable parts layout and 80°hood opening angle make maintenance easy.
Reliability
Key parts like frame and mast apply CAE top-down design to improve their strength and make the truck tough.
Technical specifications of Heli forklift 5-10 tons
| Model | unit | CPCD50 | CPCD60 | CPCD70 | CPCD85 | CPCD100 |
| Power Unit | Diesel/Gasoline/LPG/Dual Fuel | |||||
| Rated Capacity | kg | 5000 | 6000 | 7000 | 85000 | 10000 |
| Load Center | mm | 600 | 600 | 600 | 600 | 600 |
| Max.Lifting height | mm | 3000 | 3000 | 3000 | 3000 | 3000 |
| Max.Fork lifting height (with backrest) | mm | 4400 | 4400 | 4400 | 4420 | 4415 |
| Overall length (with/without forks) | mm | 3490 | 3570 | 3620 | 3960 | 4210 |
| Overall width | mm | 2045 | 2045 | 2045 | 2165 | 2165 |
| Overall height (overhead guard) | mm | 2450 | 2450 | 2450 | 2560 | 2560 |
| Wheel base | mm | 2300 | 2300 | 2300 | 2500 | 2775 |
| Min.Turning radius (exterior/interior) | mm | 3240 | 3300 | 3370 | 3650 | 3900 |
| Mast tilting angle | deg | 6/12 | 6/12 | 6/12 | 6/12 | 6/12 |
| Total weight | kg | 8300 | 9050 | 9650 | 11550 | 12660 |
| Engine mode | ISUZU 6BG1 | |||||
| Rated power | kW/rpm | 82/2000 | ||||
| Rated torque | Nm/rpm | 415/1400-1600 | ||||
| Emission | Euro IIIA | |||||
